Goodman 5 Ton Up to 18.0 SEER2 9.0 HSPF2 Variable-Speed Inverter Heat Pump Top Discharge All Regions R-32

The flagship of the GZV9SA series — maximum capacity, Goodman's best heating efficiency, in a familiar top-discharge package. The Goodman GZV9SA6010 is the most powerful unit in the GZV9SA lineup, delivering 5-ton variable-speed inverter heating and cooling at up to 18.0 SEER2 / 9.0 HSPF2 — the highest HSPF2 rating available for a 5-ton Goodman heat pump. For the largest homes and light commercial applications that need serious capacity with the intelligence of true variable-speed operation, this is Goodman's best 5-ton heat pump available. The conventional top-discharge design means installation works like any standard 5-ton condenser — but the inverter compressor inside delivers continuous, precise modulation that single-stage and two-stage heat pumps simply cannot achieve.

Why Homeowners and Contractors Choose the GZV9SA6010:

• Up to 18.0 SEER2 cooling efficiency — high-efficiency variable-speed cooling for the largest residential applications
• Up to 9.0 HSPF2 heating efficiency — Goodman's highest HSPF2 rating, the most efficient electric heating available in a 5-ton Goodman heat pump
• 5 Ton / ~60,000 BTU capacity — the most powerful unit in the GZV9SA lineup, ideal for large homes and light commercial spaces up to 2,500–3,000 sq ft
• Variable-speed inverter swing compressor — Variable / Infinite Stage — infinite modulation for precise year-round comfort and efficiency at demanding 5-ton loads
• Strong heating capacity — reliable heating output across all US climate zones for the largest applications
• Top discharge design — familiar conventional top-air-discharge configuration — no side-clearance requirements, installs like any standard 5-ton heat pump
• Custom Ivory White cabinet — premium appearance
• All Regions designation — approved for all US climate zones
• Compatible with Goodman GTST Connected Thermostat — full smart home integration
• ComfortBridge™ compatible — communicating system integration for maximum system performance
• Only two low-voltage wires in communicating mode — simplified installation for large-capacity systems
• Proprietary 7-segment LED display with fault code storage — efficient service on large-capacity systems
• High-density compressor sound blanket — noise reduction even at maximum 5-ton output
• Digitally commutated fan motor — efficient, quiet operation at high-capacity airflow demands
• Coil and ambient temperature sensors + suction pressure transducer
• ZAM® steel bottom frame and legs — maximum corrosion resistance
• Heavy-gauge galvanized-steel Ivory White cabinet — 500-hour salt-spray tested
• Hurricane-ready construction — meets 2023 Florida Building Code requirements when properly anchored
• R-32 refrigerant — one-third lower GWP than R-410A
• AHRI Certified and ETL Listed
• Made in the USA

⚠️ Backup heat source recommended for extreme cold temperatures.

⚠️ Communicating system — GTST thermostat and compatible indoor equipment required for full functionality.

⚠️ R-32 requires compatible indoor equipment with factory-installed RDS. Not compatible with R-410A.

⚠️ Field-installed bi-flow filter drier required.

Specs:

• Tonnage: 5 Ton
• SEER2: Up to 18.0
• HSPF2: Up to 9.0
• Compressor: Variable-Speed Inverter Swing (Variable / Infinite Stage)
• Refrigerant: R-32
• Discharge: Top
• Voltage: 208/230V — 1Ph — 60Hz
• MCA: ~37.5 Amps (verify on unit nameplate)
• Max Breaker (MOP): ~40 Amps (verify on unit nameplate)
• Cabinet: Custom Ivory White — Top Discharge
• Region: All Regions
• Cold Climate: No
• Operation: Heating + Cooling
• Certifications: AHRI, ETL, Energy Star 2025

Warranty: 10-year unit replacement + 10-year parts warranty with online registration within 60 days.
