Goodman 4 Ton Up to 18.0 SEER2 9.0 HSPF2 Variable-Speed Inverter Heat Pump Top Discharge All Regions R-32

High-output variable-speed efficiency for large homes — 9.0 HSPF2 heating performance in a familiar top-discharge package. The Goodman GZV9SA4810 delivers 4-ton, variable-speed inverter heating and cooling at up to 18.0 SEER2 / 9.0 HSPF2 — the highest HSPF2 rating available in a 4-ton Goodman heat pump. Unlike the Cold Climate "C" models at smaller tonnages, the GZV9SA4810 is the standard all-region configuration at 4-ton — delivering premium efficiency and inverter precision year-round for large homes across all US climate zones. The top-discharge design means conventional installation with no side-clearance concerns, while the variable-speed inverter compressor delivers the continuous, precise modulation that no two-stage or single-stage heat pump can match.

Why Homeowners and Contractors Choose the GZV9SA4810:

• Up to 18.0 SEER2 cooling efficiency — high-efficiency variable-speed cooling for large homes with lower summer electricity bills
• Up to 9.0 HSPF2 heating efficiency — Goodman's highest HSPF2 rating, delivering the lowest possible electric heating costs for 4-ton applications
• 4 Ton / ~48,000 BTU cooling and heating capacity — ideal for large homes between 2,000–2,400 sq ft
• Variable-speed inverter swing compressor — Variable / Infinite Stage — infinite modulation for precise 4-ton year-round comfort, efficiency, and quiet operation
• Strong heating capacity — maintains reliable heating output in cold conditions for large-home applications
• Top discharge design — familiar top-air-discharge configuration for conventional installation — no side-clearance requirements
• Custom Ivory White cabinet — premium appearance
• All Regions designation — approved for all US climate zones
• Compatible with Goodman GTST Connected Thermostat — smart home integration
• ComfortBridge™ compatible — full communicating system integration
• Only two low-voltage wires in communicating mode
• Proprietary 7-segment LED display with fault code storage
• High-density compressor sound blanket — quiet operation even at 4-ton loads
• Digitally commutated fan motor — efficient, quiet, long-lasting
• Coil and ambient temperature sensors + suction pressure transducer
• ZAM® steel bottom frame and legs — maximum corrosion resistance
• Heavy-gauge galvanized-steel Ivory White cabinet — 500-hour salt-spray tested
• Hurricane-ready construction — meets 2023 Florida Building Code requirements
• R-32 refrigerant — one-third lower GWP than R-410A
• AHRI Certified and ETL Listed
• Made in the USA

⚠️ Backup heat source recommended for extreme cold temperatures.

⚠️ Communicating system — GTST thermostat and compatible indoor equipment required.

⚠️ R-32 requires compatible indoor equipment with RDS. Not compatible with R-410A.

⚠️ Field-installed bi-flow filter drier required.

Specs:

• Tonnage: 4 Ton
• SEER2: Up to 18.0
• HSPF2: Up to 9.0
• Compressor: Variable-Speed Inverter Swing (Variable / Infinite Stage)
• Refrigerant: R-32
• Discharge: Top
• Voltage: 208/230V — 1Ph — 60Hz
• MCA: ~31.8 Amps (verify on unit nameplate)
• Max Breaker (MOP): ~35 Amps (verify on unit nameplate)
• Cabinet: Custom Ivory White — Top Discharge
• Region: All Regions
• Cold Climate: No
• Operation: Heating + Cooling
• Certifications: AHRI, ETL, Energy Star 2025

Warranty: 10-year unit replacement + 10-year parts warranty with online registration within 60 days.
