Goodman 5 Ton Inverter Heat Pump 16.2 SEER2 8.2 HSPF2 R32 All Regions

Goodman GZV6SA6010 5-Ton Inverter Heat Pump — All Regions

The flagship of the GZV6SA series, this 5-ton inverter heat pump delivers robust heating and cooling performance for large homes and light commercial spaces. With a purpose-built refrigerant charge and design optimized for longer line sets, it combines potent climate control with efficient operation across all regions.

Key performance and efficiency

• Up to 16.2 SEER2 / 8.2 HSPF2 for premium energy efficiency at 5-ton capacity
• 53,500 BTU/h cooling and 54,500 BTU/h heating @ 47°F
• 33,000 BTU/h heating @ 5°F; heating operation down to -10°F (-23°C)
• Variable-speed inverter swing compressor — ability to adjust across a wide range of loads

Advanced features that improve comfort and reliability

• Field-selectable Quiet Mode — as low as 45 dBA
• Electronic Expansion Valve (EEV) for precise refrigerant control
• Front AND back sealing service valves — dual-access for flexible 5-ton service
• Upgraded 1⅛" suction line + 118 oz refrigerant charge — optimized for longer line sets
• Side discharge Ivory White cabinet design
• ComfortNet compatible + GTST thermostat ready
• Proprietary 7-segment LED display with fault code storage
• Digitally commutated fan motor (0.36 HP) + high-density sound blanket
• Factory charged for 15 ft line set
• ZAM corrosion-resistant base frame and legs; hurricane-ready — meets 2023 Florida Building Code

refrigerant, compatibility, and installation notes

• Refrigerant: R-32 | Expansion Device: EEV
• Region: All Regions | Operation: Heating + Cooling
• Side discharge cabinet — review installation manual
• Communicating system — GTST thermostat required
• R-32 indoor unit compatibility with RDS required
• Field-installed bi-flow filter drier required
• Suction line adapter required: ⅞" to 1⅛"
• Backup heat recommended below -10°F

Technical specifications

• Voltage: 208/230V — 1Ph | MCA: 37.5A | MOP: 40A
• Liquid Line: 3/8" | Suction Line: 1⅛" | Refrigerant Charge: 118 oz
• Unit Weight: 179 lbs
• Heating Range: -10°F to 70°F | Cooling Range: 0°F to 115°F
• Region: All Regions | Operation: Heating + Cooling

Warranty and certifications

• Warranty: 10-year unit replacement + 10-year parts warranty with online registration within 60 days
• AHRI Certified and ETL Listed
• Made in the USA
