Goodman 4 Ton 17.2 SEER2 Two-Stage AC Condenser ComfortBridge R-32

High-output premium efficiency cooling for large homes — Goodman's best technology in a 4-ton package. The Goodman GLXT7CA4810 delivers 4-ton, 17.2 SEER2 two-stage cooling for large homes that refuse to compromise on efficiency or comfort. Approximately 25% more efficient than the federal minimum standard, with the two-stage Copeland UltraTech compressor, ComfortBridge™, CoolCloud™, and ComfortAlert™ diagnostics — this is the most advanced 4-ton AC condenser in the Goodman lineup. Keep your large home cool, comfortable, and dehumidified all summer long — at the lowest possible operating cost.

Why Homeowners and Contractors Choose the GLXT7CA4810:

• 17.2 SEER2 — Goodman's highest efficiency AC rating — approximately 25% more efficient than the 13.4 SEER2 minimum
• 4 Ton / 48,000 BTU cooling capacity — ideal for large homes between 2,000–2,400 sq ft
• Two-stage Copeland UltraTech scroll compressor — low-speed operation for quieter, more efficient cooling and superior dehumidification
• Superior active dehumidification — extended low-speed runtime removes significantly more humidity for whole-home comfort
• ComfortBridge™ communicating technology — self-optimizing system intelligence for maximum efficiency
• CoolCloud™ Bluetooth app — smartphone commissioning and diagnostics for your contractor
• Copeland® ComfortAlert™ diagnostics — proactive compressor fault monitoring
• Compatible with Goodman GTST Connected Thermostat
• Diagnostic indicator lights with storage of 6 fault codes
• Color-coded terminal strip for non-communicating setup
• Efficient two-speed ECM condenser fan motor
• High-density foam compressor sound blanket
• Copper tube / enhanced aluminum fin coil (7mm) — upgraded 7mm coil for 4-ton and 5-ton units for superior heat transfer and durability at higher capacities
• Factory-installed high and low-pressure safety switches
• Factory-installed transformer
• Ambient temperature sensors
• R-32 refrigerant — one-third lower GWP than R-410A
• Factory pre-charged for 15 ft of tubing
• Easy-access gauge ports and service valves with sweat connections
• Steel louver coil guard with rust-resistant coated screws
• Top and side maintenance access panels
• Heavy-gauge galvanized-steel cabinet with Architectural Gray powder-coat finish — 500-hour salt-spray approved
• Hurricane-ready construction — meets 2020 Florida Building Code requirements
• Cooling only — pairs with compatible R-32 indoor unit with RDS
• AHRI Certified and ETL Listed
• Made in the USA

⚠️ R-32 refrigerant requires compatible indoor equipment with RDS. Not compatible with R-410A. TXV required on indoor unit.

Specs:

• Tonnage: 4 Ton (48,000 BTU)
• SEER2: Up to 17.2
• EER2: Up to 13
• Refrigerant: R-32
• Compressor: Two-Stage Copeland UltraTech Scroll
• Fan Motor: Two-Speed ECM
• Coil: 7mm Copper Tube / Enhanced Aluminum Fin
• Voltage: 208/230V — 1Ph — 60Hz
• MCA: 26.4 Amps
• Max Breaker (MOP): 35 Amps
• Operation: Cooling Only
• Certifications: AHRI, ETL

Warranty: 10-year limited parts warranty with online registration within 60 days of installation.
