Goodman 3 Ton 21" Cased Upflow/Downflow Evaporator Coil EEV R-32 - CAPEA3626C3

The Goodman CAPEA3626C3 offers the same 3-ton capacity in a 21" cabinet, built for furnace and air handler platforms with a wider frame. It's the coil to reach for when the load calc says 3 tons but the equipment layout calls for extra cabinet width.

Key features that matter in the field

• Factory-installed EEV for precise refrigerant control in cooling and heat pump systems
• All-aluminum coil optimized for R-32 refrigerant circuits and manifolds
• Compatible with Daikin One+ communicating thermostats
• Corrosion-resistant, embossed galvanized cabinet with foil-faced insulation
• Rust-resistant, DecaBDE-free thermoplastic drain pan with secondary drain
• Single front access panel; 21" depth for easier servicing
• Fault recall of the six most recent faults

Regional readiness and important compatibility notes

• R-32 only — incompatible with R-410A equipment
• Requires a matched R-32 outdoor unit and Goodman Furnace Integration Kit (Model 0230K00044)
• Suited to homes in the ~1,500–1,800 sq ft range

Specs at a glance

• Tonnage: 3 Ton
• Cabinet Dimensions (W x D x H): 21" x 21" x 26"
• Refrigerant: R-32
• Metering Device: Internal EEV
• Line Connections: 5/16" or 3/8" liquid, 3/4" or 7/8" suction
• Ship Weight: 57 lbs
• Warranty: 10-year limited parts warranty with registration within 60 days
• AHRI Certified, ETL Listed

Why this matters for you Matching cabinet width to your existing furnace or air handler saves labor and avoids costly transition pieces. The CAPEA3626C3 gives you full 3-ton capacity in the wider 21" frame many installs already call for — no compromise on performance to get the fit right.
